VARARAM & Chuck CoW tune dyno results!!!!!!!

[POWERFREAK]

Sorry it took so long...I know it's been a topic of much debate here lately.

Here's my dyno results. I have the beta-test unit...Vararam "race" intake (requires a tune). Tuning was done by Chuck CoW. (Corvette's of Westchester in Ossining NY).

Both dyno runs were done last night on a Dynojet.

Baseline was done first...totally stock. Made 360hp/352tq.

We than swapped in the tune and the Vararam intake, and ran it again...some nice gains...peak 392hp/398tq. The highest gains (most impressively) were at 4200rpm....+46hp/+57tq

Here's 2 graphs...the second one has the #'s at 4200rpm's highlighted. Keep in mind this is still a test unit!






I can't say enough about how much better the car runs now...much more responsive and pulls much harder. Thanks to Chuck and Vararam! We've also got AR headers waiting to go on...and will get more dyno results posted.

[Cooper2010]

Holy cow! Wish we could see the same graphs with a "non-tune" version.

How is driveability? Would you recommend the "Race/Tune-only" version to someone that uses the car for a daily driver?

[Jeanius]

[Icntdrv55]

Now THAT is how a beta tester should post!! Great results Freak! Would love to see the Non Tune version graphs as well.......... from someone other then 2SSRS!

[Wacker]

I have to say WOW because the stock tune is Very Aggressive with the M6. Did you guys run a big fan? I'd really like to know what he was allowed to tweak so much.

[55Designs]

WOW

[2SSRS]

All i can say is nice, I know there is more to be had with more motor and tell Chuck nice job.

[POWERFREAK]

Originally Posted by Icntdrv55

Now THAT is how a beta tester should post!! Great results Freak! Would love to see the Non Tune version graphs as well.......... from someone other then 2SSRS!

I tried to stay quiet until I had dyno sheets in hand. It was hard, because I've been driving the car w/ the intake for a while, so I know how well it runs.

Originally Posted by Wacker

I have to say WOW because the stock tune is Very Aggressive with the M6. Did you guys run a big fan? I'd really like to know what he was allowed to tweak so much.

They had one of those "snail" looking fans...we got it as close to the grill as possible, knowing that we needed to get as much air as possible in there.

Originally Posted by Cooper2010

How is driveability? Would you recommend the "Race/Tune-only" version to someone that uses the car for a daily driver?

Driveability seems fine. I've had it installed for several weeks with no issues.

[klatterblast]

awesome

[Icntdrv55]

And I think I am speaking for many of us on this forum when I say.....Thank you for staying quiet until you had the proof!

[Bell040]

a baseline of 360 is quite low........ hot? humid?

[Chuck CoW]

Congratulations MIKE and VARARAM!



Great results! Like Mike said, all runs were last night within the same hour, No road test between intake and tune swaps. Right there on the rollers.

The bigger results are from our extensive street tune of the NEW VR RACE UNIT...To my surprise, the mid and top end of the RPM scale required almost no adjustment from the street tune, while (as we suspected...) the 3,500 and down area was a bit rich because the car was not actually moving and we didn't allow any time for the fuel trims to correct the calibration after the intake swap.

Had we taken the car off the dyno, and driven it for 20 mins, the trims would have kicked in with some correction and the low end HP and Torque would have improved nicely.

Regardless, the results were exactly what we were hoping for and I think that this unit is gonna find itself at the top of the COLD AIR INTAKE FOOD CHAIN just as the way VARARAM products dominate the Corvette world.

So far as I'm aware, the production unit is just around the corner and will absolutely be worth the wait!

What's gonna be different between last night's VARARAM results and the results you would see between the My street tune and the dyno????

Well, as I said earlier, the low speed TORQUE and HP should come up sharply after the car is street driven and the fuel trims get caught up cause the AFR on the low end was far richer than my logs of the street tune were. Another point to realize: While we're totally pleased with the WOT results from the dyno, you need to realize that this intake system is AN AIRFLOW MONSTER which gobbles up air the faster you go!

What that means is that your "REAL WORLD" results with MY tune and this intake system should improve on the top end when the vehicle is tuned at SPEED on the street.

STAY TUNED! for next weeks dyno results of Mike's ongoing progress with the addition of a set of AMERICAN RACING 1 7/8 LONG TUBE HEADERS and a CAT BACK system!

...AND BACK TO THE DYNO!!!



Stay TUNED!
Chuck CoW

[Jeanius]

Originally Posted by Bell040

a baseline of 360 is quite low........ hot? humid?

And how many miles are on the car?

[axis]

Originally Posted by Icntdrv55

And I think I am speaking for many of us on this forum when I say.....Thank you for staying quiet until you had the proof!

Lets keep in mind that this is the CAI PLUS a tune. Unlike the previous CAI only numbers that were essentially the same.

Very nice numbers. Finally something that is believeable.

[Scott@Bjorn3D]

So did you do a run at all with just the Vararam? Would of liked to seen it and then the tune afterwards just to get an idea of what the Vararam was doing by itself.

[POWERFREAK]

Originally Posted by Bell040

a baseline of 360 is quite low........ hot? humid?

no, it was a cool night...60deg, 44% humidity.

I actually did a previous baseline pull about a month ago on a mustang dyno on a hellishly humid day...and got 359hp/363tq...so it just goes to show you that all dyno's are different.

Originally Posted by Jeanius

And how many miles are on the car?

1600 miles.

[Icntdrv55]

....+46hp/+57tq with the CAI AND a tune is believable and realistic. 40 hp from JUST a CAI……….. not so believable! GREAT job Mike and Chuck. Can’t wait to see the numbers with the AR LTs!

[POWERFREAK]

Originally Posted by Scott@Bjorn3D

So did you do a run at all with just the Vararam? Would of liked to seen it and then the tune afterwards just to get an idea of what the Vararam was doing by itself.

I'm pretty sure this version wont run right without the tune.

[Badger]

..I think I just bought a CAI

[Xmicro_SS]

Nice Mike, I am not the least bit surprised. That test drive you took me on said it all. By the way, did you find all my loose change in your seat yet??

[BigMatt]

Awesome, can't wait to see the "no tune" version

[Wacker]

Again, just ask the guys who have tuned the M6. There is almost zero gain from just a tune. I'm sure Chuck Cow can attest. This really shows how restrictive the stock box is.

[themossman]

Originally Posted by Wacker

Again, just ask the guys who have tuned the M6. There is almost zero gain from just a tune. I'm sure Chuck Cow can attest. This really shows how restrictive the stock box is.

I only got 6 rwhp from a tune...

[2SSRS]

Originally Posted by Chuck CoW

Congratulations MIKE and VARARAM!



Great results! Like Mike said, all runs were last night within the same hour, No road test between intake and tune swaps. Right there on the rollers.

The bigger results are from our extensive street tune of the NEW VR RACE UNIT...To my surprise, the mid and top end of the RPM scale required almost no adjustment from the street tune, while (as we suspected...) the 3,500 and down area was a bit rich because the car was not actually moving and we didn't allow any time for the fuel trims to correct the calibration after the intake swap.

Had we taken the car off the dyno, and driven it for 20 mins, the trims would have kicked in with some correction and the low end HP and Torque would have improved nicely.

Regardless, the results were exactly what we were hoping for and I think that this unit is gonna find itself at the top of the COLD AIR INTAKE FOOD CHAIN just as the way VARARAM products dominate the Corvette world.

So far as I'm aware, the production unit is just around the corner and will absolutely be worth the wait!

What's gonna be different between last night's VARARAM results and the results you would see between the My street tune and the dyno????

Well, as I said earlier, the low speed TORQUE and HP should come up sharply after the car is street driven and the fuel trims get caught up cause the AFR on the low end was far richer than my logs of the street tune were. Another point to realize: While we're totally pleased with the WOT results from the dyno, you need to realize that this intake system is AN AIRFLOW MONSTER which gobbles up air the faster you go!

What that means is that your "REAL WORLD" results with MY tune and this intake system should improve on the top end when the vehicle is tuned at SPEED on the street.

STAY TUNED! for next weeks dyno results of Mike's ongoing progress with the addition of a set of AMERICAN RACING 1 7/8 LONG TUBE HEADERS and a CAT BACK system!

...AND BACK TO THE DYNO!!!



Stay TUNED!
Chuck CoW

As no one has the guts, Are you saying that to get the best numbers on a CAI you need to drive the car some amount of MI and can not only clear the fuel trims numbers and go,? As that is what was told to us all, and i found it to be more then 20 mi.

[axis]

Originally Posted by 2SSRS

As no one has the guts, Are you saying that to get the best numbers on a CAI you need to drive the car some amount of MI and can not only clear the fuel trims numbers and go,? As that is what was told to us all, and i found it to be more then 20 mi.

BWHAHAHA, trying to prove you were right eh?

Read his words again, especially the part you red highlighted, he said LOW END RANGE. He said NOTHING about getting more peak HP which is what the Jannety test tested for.

Please keep your personal vendetta out of other peoples USEFUL threads.

Now back to our regular viewing.
